High Speed Wet Mixer Granulating Machine with Meet GMP Standards (LM200)



Inquire Add to Basket

Port:
Shanghai, China
Transport Package:
Export Standard Wooden Case
Payment Terms:
T/T, Western Union, Paypal, Money Gram
Model NO.:
LM200
Customized:
Customized
Condition:
New
Warranty:
1 Year
Lm200 Capacity:
80-100kg
Keywords:
Granulating Machine
Material:
SUS304 or SS316
Product Name:
Wet Mixer Granulating Machine
Total Volume:
200L
Max Inside Diameter:
788mm
Power of Motor:
15kw
Rational Speed of Cutter:
50-3000rpm
Weight:
1100kg
Size:
2000X2200X1700mm
Trademark:
BSIT
Specification:
Meet with CGMP standards
Origin:
Made in China
HS Code:
8422400000
Type:
Preparation Machinery
Finished Dosage Form:
Granules
Precision:
High Precision
Certification:
CE, GMP, ISO
Voltage:
380V
Computerized:
Computerized

Product Description

High Speed Wet Mixer Granulating Machine with Meet GMP Standards (LM200)

Main use and principle:

It fits for the mixing and grain producing, it is widely used in the industry of medicine, food, chemistry and light industry.

The two processes, mixing and graining producing are completed in the same container, the powder in the fixed taper container changes to half-flowing state by milling of the blending oar and achieves complete mixing. With the immiting of the bond, powder becomes wetting. By the extrusion, attrition and pinch of the blending oar and canister cliff, powder changes to loose soft material. The soft material gradually forms small and well-proportioned humid grain by the grain producing oar.

High Speed Wet Mixer Granulating Machine with Meet GMP Standards (LM200)

Main use and principle:

It fits for the mixing and grain producing, it is widely used in the industry of medicine, food, chemistry and light industry.

The two processes, mixing and graining producing are completed in the same container, the powder in the fixed taper container changes to half-flowing state by milling of the blending oar and achieves complete mixing. With the immiting of the bond, powder becomes wetting. By the extrusion, attrition and pinch of the blending oar and canister cliff, powder changes to loose soft material. The soft material gradually forms small and well-proportioned humid grain by the grain producing oar.

1. Current display: Measuring power consumption and monitoring the granulating process.

2. Cooling of interlayer jacket of material groove: Improving quality of granule.

3. Frequency inverter adjustable speed of stirring paddle: The granule diameter can be controlled easily.

4. Frequency inverter adjustable speed of cutter: The granule diameter can be controlled easily.

5. Conical material groove: Materials can be mixed uniformly.

6. Pneumatic automatic discharge: Sealed and reliable.

7. Pneumatic pot cover lifting: Easy operation

8. The rotational speed can be controlled manually: You can try to find out the technological parameters for experiment

9. Input the set value through the touch-type keyboard to conduct program control: The quality of every batch is stable and uniform.

10. Gas filled sealing of rotating shaft: Preventing the rotating shaft from being bonded by dust.

11. Water-spraying cleaning of rotating shaft: Easy cleaning and short cleaning time

12. The parts that touch material are mare made of (polished) stainless steel: Meeting the specifications of GMP.

13. Appropriate height of discharge outlet: It can be used together with the drying equipment.

14. Can be equipped with PLC and human machine interface.

Technical Parameters (The right of alteration is reserved):

Model/specifications		Din	LM10	LM50	LM100	LM200	LM300
Material Groove	Total Volume	dm3	10	50	100	200	300
	Service Capacity	dm3	2-7	12-35	25-70	80-100	120-150
	Max inside Diameter	mm	294	500	640	788	988
Driving System	Rotational Speed of Stirring Paddle	r, p, m	100-1000	20-500	8-250	30-250	30-200
	Power of Motor	KW	2.2	5.5	7.5	15	20
	Rational Speed of Cutter	r, p, m	50-3000
	Power of Motor	kw	0.75	1.5	3	4	7.5
Weight Dimensions	Length (L)	mm	1500	2000	2400	2200	2400
	Total Height (H)	mm	1300	1500	1560	2000	2300
	Height of Discharge Outlet (h)	mm	700	700	730	930	930
	Width (B)	mm	600	760	900	1700	1800
	Weight of Machine	kg	260	400	700	1100	1300
