Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)

  • Shanghai, China

  • 20 Sets/Month

  • T/T, Western Union, Paypal, Money Gram

  • CT

  • Customized

  • New

  • 1 Year

  • 100kg/Time

  • Electrical Heating

  • Explosion Motor

  • SS304 Stainless Steel

  • Pharmaceutial or Food Powder Granule

  • 1.1kw

  • 20

  • 48PCS

  • 2430X1200X2375

  • 1200kg

  • BSIT

  • Export Standard Wooden Case

  • Meet GMP Standard

  • Made in China

  • 8422400000

  • Preparation Machinery

  • Granules

  • High Precision

  • GMP, ISO

  • 380V

  • Computerized

Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Application:


It is suitable for heating and solidification, drying and dehydration of raw materials in pharmaceutical industry, chemical industry, foodstuff industry, agricultural and sideline products, aquatic products, light industry, heavy industry and so on. The raw materials can be medicine of raw materials, Chinese traditional medicine, tablet of drink, immersed electuary, powder, granule, packing bottle, pigment, dyestuff, dehydration vegetable, dried fruit and melons, banger, plastic resin, electric elements, drying varnish and so on.
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)
Double Door Hot Air Circulation Drying Oven/Pharmaceutical Drying Machine (CT)

Main technical parameters:

1). The hot source can be steam, electricity, far infrared, or steam + electricity.

2). Temperature of operation: 50~140.

3). 50~350 for electricity or far infrared.

4). There are automatic and computer control systems for customer selection.

5). The normal pressure of steam will be 0.02~0.8Mpa.

6). The size of drying tray: 460X640X45.

Technical Parameters:
Parameter Type Dry amount kg/times Power(kw) Consumption of steam (kg/h) Amount of tray Overall dimensions (mm) Amount of trolley Weight(kg)
CT-I 100 1.1 20 48 2430X1200X2375 2 1200
CT-II 200 1.1 40 96 2430X2200X2433 4 1500
CT-III 300 2.2 60 144 3430X2200X2620 6 2000
CT-IV 400 2.2 80 192 4380X2200X2620 8 2300
CT-C-O 25 0.45 5 8 1200X1000X1750 0 800
CT-C-IA 50 0.45 10 24 1400X1200X2000 1 1000
CT-C-I 100 0.45 18 48 2300X1200X2000 2 1500
CT-C-II 200 0.9 36 96 2300X2200X2000 4 1800
CT-C-IIA 200 0.9 36 96 4460X1200X2290 4 1800
CT-C-III 300 1.35 54 144 3300X2200X2000 6 2200
CT-C-IIIA 300 1.5 54 144 2300X3220X2000 6 2200
CT-C-IV 400 1.8 72 192 4460X2200X2290 8 2800
