LPG-5 Series High Speed Centrifugal Spray Drier

  • Shanghai, China

  • 50 Sets/Year

  • L/C, T/T, Western Union, Paypal, Money Gram

  • LPG-5

  • 5 Kg/H

  • 25000

  • 50mm

  • Spraying Drier

  • Continuous

  • Air

  • Bulk

  • Spraying

  • Contra-Flow

  • Rotary Atomization

  • BSIT

  • Wooden Case

  • Meet with CGMP standards

  • Made in China

  • 8422303090

  • Transmission

  • Powder, Solution

  • Gas Atomization

  • Contra-Flow

  • Electricity, Steam

  • Centrifugal Spray

LPG High Speed Centrifuge Spray Dryer


Food Industry: Whole milk powder, cocoa milk powder, milk substitute, egg white (yolk), etc. Armpit prion, Oats, chicken juice, instant tea, seasoning meat, protein, soybean, peanut protein, protein hydrolyzate, etc. Corn syrup, corn starch, glucose, pectin, maltose, potassium sorbate, pumpkin powder, etc.
Pharmaceutical products: Chinese traditional medicine extract (herb extract), medicine colloid, yeast, vitamins, antibiotics, amylase, lipase, etc. Plastics resin: AB, ABS emulsion, urea-formaldehyde resin, phenolic resin, dense plastic (urea) formaldehyde resin, polyethylene, polyvinyl chloride, etc. Detergent: Advanced washing powder, normal washing powder, soap powder, soda powder, emulsifiers, brighteners, phosphoric acid agents. Chemical Industry: Sodium fluoride (potassium), alkaline dyestuff and pigment, dye intermediates, Mn3O4, formic silica acid, catalyst, sulfuric acid agent, amino acids, silica, etc...Ceramic: Aluminum oxide, ceramic tile material, magnesium oxide, talc, etc.

LPG-5 Series High Speed Centrifugal Spray Drier


Air is turned into hot air through heater and enters into hot air distributor at the top of dry chamber and then enters into dry chamber and rotates in the state of helix. At the same time liquid of raw material is sent to centrifugal atomizer at the top of dry chamber through stepless variable screw pump. In which liquid of raw material atomizes small drops. Air and liquid of raw material flow and contact each other. The moisture vaporizes rapidly. Liquid of raw material is dried into finished product in a short time. The finished product is discharged through the bottom cyclone separator of drier and the wasted air is exhausted through fan.


The drying speed is very quick. When raw material is atomized, the surface area increases greatly. 65~98% of moisture can be vaporized in hot air stream momentary. The dry time to be used is only 5~15 seconds. Especially, it is suitable for drying thermal sensitive raw materials.
The size of finished product is uniform and the flow and solubility are good. The purity and quality of product are good too.
The operation is stable and simple. The regulation and control is very convenient. It is easy to realize automatic operation.
The operation process is simplified and the operation environment is superior and can avoid powder dust during the period of operation.


Chemical industry: Sodium (potassium) fluoride, alkali dyestuff and pigment, dyestuff intermediate, compound fertilizer, catalyst, amino acid, white black and so on.
Plastic resin: ABS emulsion liquid, urea formaldehyde resin, phenol formaldehyde resin, formaldehyde resin, PE, PVC and so on.
Foodstuff industry:
Egg and milk products: Rich lipoprotein powdered milk, cocoa powdered milk, baby meal, egg white, vitalize and so on, food and juice of plant, oat, chicken juice, coffee, crystalline tea, condiment and flavor, protein bean, earthnut protein, protein, hydrolysis and so on.
Sugar: Maize paste, maize starch, glucose, pectin, maltose, potassium seriate and so on

machine showroom

LPG-5 Series High Speed Centrifugal Spray Drier
LPG-5 Series High Speed Centrifugal Spray Drier

Technical data:
MODEL LPG-5 LPG-25 LPG-50 LPG-100 LPG-150 LPG-200~2000
Inlet temperature 140~350 ºC
Outlet temperature 80~90 ºC
Water evaporation capacity(kg/h) 5 25 50 100 150 200~2000
Revolution (rpm) 25000 18000 18000 18000 15500 8000~15500
Diameter of atomizing disc (mm) 50 120 120 120 150 180~240
Heat source Electricity Electricity Steam+electricity, oil, fuel, gas Solved by user
Max. power of electric heater (kw) 9 48 72 81 99 /
Overall dimensions (m) 1.8X0.93X2.2 3X3.2X5.1 3.7X3.2X5.1 4.6X4.2X6 5.5X4.5X7 1800
Recovery rate of dry powder (%) ≥95
