Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical

  • Shanghai, China
  • 200 Tons/Month
  • T/T, Western Union, Paypal, Money Gram
  • PVC/PE
  • 0.3mm
  • Oral Liquid or Cosmetic or Pescide
  • 2 Filling Head or 5 Filling Head or More
  • Plunger Pump
  • Vacuum
  • Pneumatic Lifting
  • Linear
  • Plastic Ampoule or Bottle or Bag
  • Plastic PVC/PE Film
  • 40kg/Roll
  • BSIT
  • Export Standard Wooden Case or Paper Case
  • meet with GMP standards
  • Made in China
  • 8422303090
  • PVC
  • Packaging Film, Logistics Film, Food&Medicine Film, Decorative Film
  • Shrink Film
  • Transparent
  • Rigid
  • Blow Molding
PVC/PE rigid film Introduction:

Due to PE has good heat sealing ability, it can not obstruct the gas but it can obstruct the fluid very well. It is good for fluid medicine packing.
Some factories used old glass bottles before, it has two fatal defects:
1. It is easy broken when you are opening.
2. The fluid in it is easy to expand and crash the bottle when it has fermented. So it will damage the product packaging.
Pharma-grade PVC/PE composite film has kept away from the two defects above. It is mainly produced by officinal PVC film, then heat seal PE film. During the producing, the temperature, coated quantum and solid time are measured strictly to make sure that the product can meet the standard of the same product in the international. The heat sealing ability is 4 times higher than common PVC film. It also has good rigidty, flexility, cash resistance and dilatability. It is suitable for packing all kinds of fluid medicine.

A. Normal technical parameter and standard
1, Appearance size
Pictures Items Specification (mm) Tolerance (mm)
Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical Thickness 0.3 (normal) ±0.025
Width 345 (normal) ±1
Inner core diameter 76mm
Outside diameter Less than 350mm (normal)
Weight /reel About 40kgs (normal)

2, Appearance quality
The luster transparent is consistent, does not allow any cracks, scars, the accident, perforation, separates out, lacks, greasy dirt. Roll leveled, cut trim, same elasticity.

B. Technical parameter:

Items Technology requirement Results Verdict
Appearance Should accord prescribe Accord prescribe Accord
Physics capability Water Vapor Transmission
24 h - 23°C - 90% RV - 1 atm
≤2.5g/(m2.24h) 0.8g/(m2.24h) Accord
Oxygen Transmission
24 h - 23°C - 75% RH - 100% O² - 1atm
≤20cm3/(m2·24h·0.1MPa) 11cm3/(m2·24h·0.1MPa) Accord
Stretch Elongation Both lengthways and landscape orientation average should more than 40Mpa lengthways:51Mpa
landscape orientation :53MPa
Accord
Strike intensity Both lengthways and landscape orientation should not appear more than two pieces damaged lengthways:No damaged
landscape orientation:
No damaged
Accord
Heat up extend and draw back Within ±6% Lengthways:-1.7%
Landscape orientation :+0.8%
Accord
Heat sealing intensity ≥6.0N/15mm 125 N/15mm Accord
Residual Solvent ≤10mg/ m2 2.7mg/ Accord
Chloroethylene monomer No more than millionth Accord
dissolved matter test Clear degree Colorless, if turbid, compare with No.2 normal turbidity liquid and not more deeper than it Accord prescribe Accord
Facility oxide the distance of wasting between water liquid and blank liquid should not more than 1.5ml 0.63ml Accord
Heavy metal No more than millionth Accord
Fixed matter water ≤30.0mg/100ml 5.9mg/100ml Accord
65%ethanol ≤30.0mg/100ml 7.6mg/100ml Accord
hexane ≤30.0mg/100ml 9.5mg/100ml Accord
Microbial limits Amount of Microbe ≤1000/100cm2 No check out Accord
Amount of Mildew
and Microzyme
≤100/100cm2 No check out Accord
Amount of coliform Should not appear No check out Accord

Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical
Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical
Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical
Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical

Hot Sale PVC/PE Plastic Ampoule Forming Packing Film Materical
