Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine

  • Shanghai, China
  • 20 Sets/Month
  • L/C, T/T, Western Union, Paypal, Money Gram
  • DSM-120
  • Vacuum
  • Pneumatic Lifting
  • Linear
  • Bottle
  • Plastic
  • Plastic Ampoule Filling Sealing Machine
  • Vape Cartridge Filling Machine
  • 2-25ml/Ampoule
  • 0-50 Time
  • 2 and 5 and 10 and 15 Filling Heads
  • 50-100PCS/Min
  • PVC/PE or Pet/PE
  • 3.5kw
  • SS316 Contact with Liquid
  • Pharmaceutical, Cosmetic,Oral,Oil, Pesticide
  • 220V.50Hz,1p
  • 350-450
  • BSIT
  • Export Standard Wooden Case
  • meet with GMP standards
  • Made in China
  • 8422400000
  • Plastic Ampoule Filling Sealing Machine
  • Automatic
  • Liquid
  • Multi-Head
  • Multi-Room Feeding
  • Plunger
DSM-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine

Machine main Advantage:

1.DSM-120 Micro Liquid Forming Filling & Sealing Machine is applicable for liquid, sticky, semi-sticky and so on.
2.This machine can be used for pharmaceuticals, food, health care products, cosmetic. It also can be used in industry and agriculture in similarity products.
3. This machine can finish forming, filling,sealing ,cutting once time.
4. our machine has 2 filling head, 5 filling head, 10 filling head, 15 filling head. you can choose freely according to difference capacity
5. Meet with CE certificate and GMP standards

Working process:

Take out the film, Plastic bottle-forming, filling, date printing, sealing and cutting can be completed automatically. Save cost and time.
This machine is applied to fill liquid or semiliquid, such as pharmaceutical/chemical/food/oral liquid, E-liquids, oil, cosmetic (shampoo, cream) and honey etc.
This machine is widely used in pharmacy, daily cosmetic, petrochemical and foodstuff etc industries.


Features:

1. Controlled by PLC, the frequency conversion in finely variable speeds.
2. All 6 processes from spreading roll, AMP bottle forming, filling, sealing the end,
printing serial numbers, cutting the end ,cutting apart, controlled by programming.
3. The computer human interface has simple and clear operation.
4. The filling head does not drop, leak, rise in bubbled and spill over.
5. All are made of high-quality stainless steel, accord with the standard GMP.
6. Mostly pneumatic components and wirings adopt inward fittings.
7. Automatic and mechanical filling, precise calculation and limited deflection.


2 filling head plastic ampoule filling machine working video please check https://youtu.be/laeN9l3s3d4
5 filling head plastic ampoule filling machine working video please check https://youtu.be/N0t2_QKAC-4

10 filling head plastic ampoule filling sealing machine working video please check: h ttps://youtu.be/hOlET10kpOo
Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine
Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine




Related plastic ampoule forming filling sealing machine
Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine

Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine
Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine


Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine

Dsm-120 Five Heads Ampoule Oral Liquid Bottle Forming Filling Sealing Machine
Technical Parameter:
Model DSM-120(Two filling nozzles)
Maximum forming depth 12mm
Cutting frequency 0-25time
Maximum capacity 50bottles/min
Packing material PVC/PE film(0.2-0.4)x120mm
Filling volume 2-25ml/bottle
Power 3.5Kw
Power supply AC,220V/50Hz 1Phase or customization
Net weight 350kg
Overall size 1800x800x1400mm
Model DSM-120(Five filling nozzles)
Maximum forming depth 12mm
Cutting frequency 0-25time
Maximum capacity 100bottles/min
Packing material PVC/PE film(0.2-0.4)x120mm
Filling volume 2-25ml/bottle
Power 3.5Kw
Power supply AC,220V/50Hz 1Phase or customization
Net weight 450kg
Overall size 2200x900x1500mm
