Shanghai, China
30 Sets/Year
T/T, Western Union, Paypal, Money Gram
BMT
Bottles
40-100 PCS/Min
Round Bottle
Vertical Round Bottle Labeling Machine
Labeling Machine
SUS304
Diameter Min 20mm, Max 120mm
Length: 30~200mm Width: 20~90mm
Internal Dia. 76mm External Dia. 300mm
220V,50Hz,1kw
400kgs
BSIT
Export Standard Wooden Case
Meet GMP Standard
Made in China
8422303090
Automatic
Cosmetics, Drinks, Cleaning, Detergent
Sticker Labeling Machine
Electric
Automatic Vertical Round Bottle Labeling Machine
Paper
vertical Round Bottle Labeling Machine Automatic Sticker Packing Machine
General Features:
Automatic labeling machine for the application of labels on round bottle. The machine is composed by a conveyor, one of label adaptor and one of label applicator. In case of wrap around label application a side conveyor is installed. There is also the possibility to install a hot stamping unit, print expiry date, batch code etc. The bottle loading/unloading can be done manually, through loading/unloading turntable (alternative Ø620mm or Ø900mm) or directly from an production line.
Technical Features:
| Kind of bottle | Round |
| Bottle size | Min. Ø20mm Max. Ø120mm |
| Speed | Step motor SMT-A: 15m/min Servo motor SMT-B: 25m/min |
| Label size | Length: 30~200mm Width: 20~90mm |
| Label roll size | Internal dia. Ø 76mm External dia. Ø 300mm |
| Power | 220V 50/60Hz 1.0kw |
| Machine size mm | Length 2000, width 900, height 1500 |
| Machine weight | 400kgs |
* Other sizes on request
labeling bottle /ampoule sample
vertical Round Bottle Labeling Machine Automatic Sticker Packing Machine
General Features:
Automatic labeling machine for the application of labels on round bottle. The machine is composed by a conveyor, one of label adaptor and one of label applicator. In case of wrap around label application a side conveyor is installed. There is also the possibility to install a hot stamping unit, print expiry date, batch code etc. The bottle loading/unloading can be done manually, through loading/unloading turntable (alternative Ø620mm or Ø900mm) or directly from an production line.
Technical Features:
| Kind of bottle | Round |
| Bottle size | Min. Ø20mm Max. Ø120mm |
| Speed | Step motor SMT-A: 15m/min Servo motor SMT-B: 25m/min |
| Label size | Length: 30~200mm Width: 20~90mm |
| Label roll size | Internal dia. Ø 76mm External dia. Ø 300mm |
| Power | 220V 50/60Hz 1.0kw |
| Machine size mm | Length 2000, width 900, height 1500 |
| Machine weight | 400kgs |
* Other sizes on request
labeling bottle /ampoule sample
