Labeling Machine for Liquid Bottle



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
30 Sets/Year
Payment Terms:
T/T, Western Union, Paypal, Money Gram
Model NO.:
BSMT-A
Material Type:
Bottle or Box
Packaging:
Bottles
Packaging Material:
Plastic
Name:
Labeling Machine for E-Cig Liquid Bottle
Bottle Specification:
Dia 10-20mm
Label Specification:
Length: 30-200mm Width: 20-90mm
Label Accuracy:
+/-0.5mm
Keywords:
Labeling Machine
Size:
Length 2000, Width 900, Height 1500
Speed:
Step Motor or Servo Motor
Materical:
SUS304
Label Roll Size:
Internal Dia.76mm External Dia. 300mm
Weight:
400kgs
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
Meet GMP Standard
Origin:
Made in China
HS Code:
8422303090
Automatic Grade:
Automatic
Application:
Cosmetics, Drinks, Vegetable, Fruit
Type:
Labeling
Forming Species:
Bottle Labeling
Forming Function:
Labeling
Driven Type:
Mechanical

Product Description

General Features:

Automatic labeling machine for the application of labels on round bottle. The machine is composed by a conveyor, one of label adaptor and one of label applicator. In case of wrap around label application a side conveyor is installed. There is also the possibility to install a hot stamping unit, print expiry date, batch code etc. The bottle loading/unloading can be done manually, through loading/unloading turntable (alternative Ø620mm or Ø900mm) or directly from an production line.

Labeling Machine for Liquid Bottle

Technical Features:

Kind of bottle	Round
Bottle size*	Min. Ø20mm Max. Ø120mm
Speed	Step motor SMT-A: 15m/min	Servo motor SMT-B: 25m/min
Label size	Length: 30~200mm Width: 20~90mm
Label roll size*	Internal dia. Ø 76mm External dia. Ø 300mm
Power*	220V 50/60Hz 1.0kw
Machine size mm	Length 2000, width 900, height 1500
Machine weight:	400kgs
