5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate

  • Shanghai, China
  • 30 Sets/Year
  • T/T, Western Union
  • SMT-A
  • Bottles
  • +/-0.5mm
  • Dia 10-20mm
  • Length: 30-200mm Width: 20-90mm
  • BSIT
  • Export Standard Wooden Case
  • Meet GMP Standard
  • Made in China
  • 84223030
  • Automatic
  • Cosmetics, Drinks, Vegetable, Fruit
  • Automatic Labeling Machine
  • Mechanical
  • Plane Labeling Machine
  • Plastic
General Features:

Automatic labeling machine for the application of labels on round bottle. The machine is composed by a conveyor, one of label adaptor and one of label applicator. In case of wrap around label application a side conveyor is installed. There is also the possibility to install a hot stamping unit, print expiry date, batch code etc. The bottle loading/unloading can be done manually, through loading/unloading turntable (alternative Ø620mm or Ø900mm) or directly from an production line.

5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate

labeling sample:

5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate


Technical Features:
Kind of bottle Round
Bottle size* Min. Ø20mm Max. Ø120mm
Speed Step motor
SMT-A: 15m/min
Servo motor
SMT-B: 25m/min
Label size Length: 30~200mm Width: 20~90mm
Label roll size* Internal dia. Ø 76mm
External dia. Ø 300mm
Power* 220V 50/60Hz 1.0kw
Machine size mm Length 2000, width 900, height 1500
Machine weight: 400kgs

* Other sizes on request
5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate
5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate
5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate
5-30ml Pet Bottle Labeling Machine Meet with Ce Certificate
