Single chamber Tea bag packing machine Model DXDC15 for CTC black tea or green tea or hearb granulte
Choose our machine advantage:
1.Our single chamber teabag packing machines include more than 10 models machines with different structure and various functions.
2.They could meet the packing request of tea, flower tea, herbal tea, medical tea and tea foods.
3.These machines are using the heat-seal filter paper and the technology of heat forming. One complete machine can finish all functions automatically, such as forming, filling, bag sealing, cutting, tag pasting, thread winding, envelope sealing, feeding, date and batch number printing.
4.Some of them could even count and put bags into box automatically.
5. have other name: Tag: Tea Bag Packing Machine, CTC Black Tea Bag packaging machine, Green Tea bag Packing machinery,Tea Packing Machine, Hearb Granulate Packing Machine, Tea Packing Machine with high speed , Tea Packing Machine with bag counter device, Tea Packing Machine with tag pasting, thread winding, Tea Packing Machine with thread winding. Main Feature:
1.Tea bag packing machine Model DXDC15 is our new model, it is update new model on the DXDC8IV. this model similar with our model DXDC8IV, but enlarge the content of filter tea bag and envelope
2. It features filling, heat sealing, threading, labeling and over-wrapping functions.
3.Meanwhile, it also has an adjustable loading system for filling different size tea bags. Adopting sealing pads in place of the sealing rollers used in machines of previous generations,
4. This new system greatly improves the machine's flexibility and enables use of different packaging materials. Main materials include paper/PE, plastic/foil/PE and plastic/PE. Technical Parameter
|Capacity ||105±5bags/minute |
|Max.filling volume ||10cm3 |
|Bag dimensions ||65mm x 62.5mm |
|Envelope dimensions ||82mm x 75mm |
|Tag dimensions ||28mm x 24mm |
|Thread length ||220mm |
|Power supply ||AC 380V / 220V |
|Total power ||2.5KW |
|Net Weight ||1210kg |
|Gross weight ||1410kg |
|Overall dimensions ||1688mm x 1330mm x 2205mm |
|Carton dimensions ||1840m x 1290m x 1890m |
tea bag Sample:
