Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

  • Dalian, China

  • 10 Sets/Month

  • L/C, T/T, Western Union, Paypal, Money Gram

  • ZPT

  • Customized

  • New

  • 1 Year

  • Zpt15/17/20/25

  • 70,000 PCS/H

  • SUS304 with Product

  • Forced Feeder

  • Pre Pressure

  • D Model

  • 25mm

  • 20mm

  • 100kn

  • 12mm

  • BSIT

  • Export Standard Wooden Case

  • meet with CGMP standards

  • Made in China

  • 8438800000

  • Preparation Machinery

  • Tablet

  • High Precision

  • CE, GMP, ISO

  • 380V

  • Computerized

ZPT Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine
Rotary Tablet Press


Choose our ZPT tablet press Reason?

1.The contact with product adopt SS304/SS316 stainless steel.
2.The hole of the punch¨ is with special anti-leakage and anti-dust device.
3.Convience for disassemble structure, make sure the maintenance.
4.Adopt high desinition, isolated window design.Adopt reliable safe sealing and dustproof design.
5.The force feeder system solves the shortage situation of normal tablet pressing machine.
6.Make the engineer's motive power transmit to enforced transimission shafte directly, and then over the transmission box and feeder impeller, achieing the enforced feeder system and saving the less down material from gravity, too much powder in working tray and inter-pollution of ordinary machine
7. With CE certificate and Meet with GMP certificate
8.Quality guarantee for 1 year
9. with 1 year spare part for free
10. with 1 set of mould is free
11. mould Die type for D/B/BB/BBS As optional
12. working video please https://youtu.be/M-oPHrywYrk

Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press
Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press
Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press
Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

with spare part and document
Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

Forced feeder system

Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press
.
The powder recovery system solves the cross contamination.

Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

Machine main drawing as following:

Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

Tablet Sample:


Zpt Pill/ Candy/ Cartoon Tablet/ Medicine/ Pharmaceutical Machine/ Tablet Making Machine Rotary Tablet Press

Technical Parameter:

Model ZPT15 ZPT17 ZPT20 ZPT25
Die type D B BB BBS
Number of dies 15 17 20 25
Max. diameter of tablet (mm) 25 16 13 11
Max abnormal Prolate axis size (mm) 25 18 16 _
Maxoutput (tablets/h) 70000 80000 95000 118000
Maximum filling depth (mm) 20 16 16 16
Maximum main pressure (KN) 100 80 80 80
Maximum pre-pressure (KN) 12 12 12 12
Idle load noise dB(A) < 75
Power of main motor (KW) 380V 50HZ 5.5KW
Size of machine (mm) 660× 690× 1620
Net weight of machine (kg) 675
