Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)

1.Controlled by PLC , the frequency conversion in finitely variable speeds.
2. All 6 processes from spreading roll, Ampoule bottle forming, filling , sealing the end , printing serial numbers, cutting the end,
cutting apart, controlled by programming
3. The computer human interface has simple and clear operation.
4. The filling head don't drop. Leak, riding bubbled and spill over.
5. All are made of high-quality stainless steel, accord with the standard GMP.
6. Mostly pneumatic components and sirings adopt inward fittings.
7. Automatic and mechanical bottling, precise calculation and limited deflection
  • DSM
  • BSIT
  • 8422303090
  • Dalian, China
  • 30 Sets/Year
  • L/C, T/T, Western Union, Paypal, Money Gram
  • 1 set
  • export case

DSM Liquid Filling Machine is high-end product which is our latest development. It is used to fill kinds of liquid and semi-liquid products.

plication:
1. Suitable for Oral liquid,liquid,pesticide,perfume,cosmetics and pulp food category ,etc

2. it can produce the stand-up, shaped and independent plastic tube

Main advantage:

1.Controlled by PLC , the frequency conversion in finitely variable speeds.
2. All 6 processes from spreading roll, Ampoule bottle forming, filling , sealing the end , printing serial numbers, cutting the end,
   cutting apart, controlled by programming
3. The computer human interface has simple and clear operation.
4. The filling head don't drop. Leak, riding bubbled and spill over.
5. All are made of high-quality stainless steel, accord with the standard GMP.
6. Mostly pneumatic components and sirings adopt inward fittings.
7. Automatic and mechanical bottling, precise calculation and limited deflection



Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)

Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)

Photo for sample

Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)

Technical Parameter:

Packing  film PVC/PE  outer  diameter: ≤  diameter 600MM
Thickness  0.1-0.5mm    inner  diameter  : Φ 70-76mm
Width: 100 -240mm, bottle depth:5-25mm
Packing  capacity 1.5-60ml
Packing  efficiency ≤ 35plates/min
Water  consumption 4.6L/min
Air  consumption 300L/min
Power 35Kw
Power  Supply 380V/50Hz
Overall  Dimension 5000x3000x
Weight 3150KG
Yield  Table
Packing  dose Packing  width Packing  Qty/row Cutting  frequency
5 17.4 12 32
10 21 10 40
20 26 8 35
30 35 6 35
50 52.5 4 35
60 52.5 4 30



Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
Stand-up Perfume Plastic Ampoule Liquid Forming Filling Sealing Packing Machine (PVC/PE Bottle)
