RC-6D Tablet Dissolution Tester

  • Shanghai, China
  • 7 Sets/Week
  • T/T, Western Union, Paypal, Money Gram
  • RC-6D
  • Computer Control
  • 0-100Kg
  • AC220V
  • Under
  • 20-200 Rpm
  • BSIT
  • Export Standard Wooden Case
  • Meet GMP Standard
  • Made in China
  • 9027809000
  • Universal Testing Machine
  • <1000KN
  • 1
  • Electronic Load
  • Static Load
  • Digital
RC-6D DISSOLUTION TESTER
RC-6D Tablet Dissolution Tester


Production Description
RC series of instruments are used for detecting velocity and extent of pharmic dissolution from tablet, capsule etc in prescriptive menstruum.

Applicable standards:
National standard( Chinese codex ) /2015
Corporate standard(Dissolution tester )Q/12XQ0187-2010

Features:
It has six vessels and six poles arranged on one line.
The head moves up/down automatically.
The basket units and paddle units are made of imported stainless steel (SUS316L).
The magnetism-pumped circular water current can heat the system evenly, and the bath liquid can achieve an equal temperature.
A MPU is used in dissolution tester to automatically control the temperature, rotational speed and time, and the parameters can be preset at any time.
It can be operated conveniently by keystroke. The measurement result is displayed by LED. The preset and real data can be displayed alternately in time.
Automation: auto-test, auto-diagnose, auto-alarm.
It can test by self and alarm automatically. The dissolution parameters of' Chinese codex 2010' are stored in and can be taken out at anytime.
Time can be preset at many points. The beeper sounds automatically to any point, and then the tester automatically runs to the next one.

Technical Parameter :
Speed range (20~200)rpm
Speed accuracy ±2rpm
Temperature range ambient to +45.0ºC
Temperature Stability ±0.3ºC ±0.3ºC
Preset timing nine points (1~900)min
Time accuracy ±0.3%
Basket radial run-out ±1.0mm
Paddle radial run-out ±0.5mm
Heating power 1000w
Working time continuously More than 24hours
Power 220V50Hz ,1200W
Dimension 960×40480mm3

RC-6D Tablet Dissolution Tester

RC-6D Tablet Dissolution Tester
RC-6D Tablet Dissolution Tester
RC-6D Tablet Dissolution Tester
RC-6D Tablet Dissolution Tester
