Nqf1500 Capsule and Powder Machine Separately Automatically



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
20 Sets/Month
Payment Terms:
T/T, Western Union, Paypal, Money Gram
Model NO.:
NQF1500
Customized:
Non-Customized
Condition:
New
Warranty:
1 Year
Name:
Capsule and Powder Machine Separately
Keywords:
Capsule and Powder Machine Separately
Power Supply:
220 V50/60Hz 0.2kw
Capsule Model No.:
0# 1# 2# 3# 4#
Function:
Get Capsule and Reuse Powder, Granules, Pellets,
Capacity:
300-1500PCS/Min
Working Model:
Open Capsule Get Poweder/Granule
Dimension:
600X600X1200mm
Weight:
50kg
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
GMP
Origin:
Made in China
HS Code:
8422400000
Type:
Capsule and Powder Separately
Finished Dosage Form:
Capsule
Precision:
Precision
Certification:
GMP
Voltage:
220V
Computerized:
Non-Computerized

Product Description

Nqf1500 Capsule and Powder Machine Separately Automatically

Main Feature:

1.This is the world first machine designed to separate capsule and reuse powder, granules, pellets, or micro-tablets which is built to replace the traditional way of milling, sieving and retrieving powder.
2.machine is first of its kind to separate and retrieve round pellets and micro-tablets.
3.It is ergonomically designed; suitable for all capsule sizes with applicable change parts; easy to clean and maintain;
4.It is meet the GMP standard in the industry.
5. It is excellent machine to own by capsule manufacturing plants or R&D laboratories, where powders are extremely expensive and GMP is strictly required.

Nqf1500 Capsule and Powder Machine Separately Automatically

Drawing :

Nqf1500 Capsule and Powder Machine Separately Automatically

WORKING PRINCIPLE:

The capsules enter through the guide from the sorting system are pushed into separating device by the horizontal fork. The blades on the device hold the cap and body of the moving capsules. The capsule moving according to the opening rail formed by the blades; then, it will separate the body and cap of capsule completely.

TECHNICAL PARAMETER:

Type Item	NQF300/600/800B	NQF1500B
Capacity	100~800pcs/min	1500pcs/min
Capsule Size	0# 1# 2# 3# 4#	0# 1# 2# 3# 4#
Power	~220V 50HZ 1A	~220V 50HZ 1A
Dimension	600×600×1200mm	600×600×1200mm
Weight	45kg	50kg

PACKING LIST
NO.	Name	Type	Qty	Unit
1	Main Machine	NQF300/600/800/1500	1	set
2	Molder with the machine			set
3	Optional molder			set
4	Spare Blade			set
5	Spare Blade			set
6	Spare Blade			set
7	Spare Blade			set
8	Special Tools		2	set
9	Big Spring Plate		1	set
10	Small Spring Plate		6	set
11	QC cert		1	set
12	Manule		1	set
