Laboratory Use Single Punch Pill Press Machine for Candy Tablet Dp12 Introduce: 1. DP-12 model single tablet press machine is to absorb advanced technology successfully developed.
2. It is pharmaceutical, laboratory and other industries first choice and able to press the powder and granular material into tablets continuously and automatically.
The advantages are: 1.Materials high utilization, reasonable structure, convenient operation, small size, the depth of filling material and the thickness of the tablet can be continuously adjusted.
2. All the function index of advanced machine level and full compliance with national GMP standard.
3. Machine used in the design process a number of innovative designs, thus ensuring the production process more secure and standardized.
Photo for DP12 tablet press
Photo for DP25 tablet press our Tablet press showroom:
With stainless steel table DP12 single punch tablet press
related lab mixer machine Mould photo:
Technical Parameters: | Model | DP-12 | DP-25 |
| Production Capacity | 3600pc/h | 3600pc/h |
| Max. Pressure | 50kn | 50kn |
| Max. Tablet Diameter | 12mm | 25mm |
| Filling Depth | 20mm | 20mm |
| Max. Tablet Thickness | 8mm | 8mm |
| Power | 220V 50Hz 1.1kw | 220V 50Hz 1.5kw |
| Dimension | 450*550*750mm | 550*600*900mm |
| Weight | 100kg | 200kg |
Sample:
