Inspection Machine for Tablet and Capsule (YJX-220)



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
20 Sets/Year
Payment Terms:
T/T, D/P, Western Union, Paypal, Money Gram
Model NO.:
YJX
Customized:
Customized
Condition:
New
Warranty:
1 Year
Name:
Tablet Capsule Inspetion Machine
Keywords:
Inspection Machine
Capacity:
120,000 PCS/H
Dimensions:
1400X650X1230
Weight:
180kg
Power:
0.75kw
Capsule or Tablet:
Capsule00#-4#and Pill, Tablet Diameter Less Than 2
Suitable Range:
Tablet or Capsule
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
Meet GMP Standard
Origin:
Made in China
HS Code:
8422303090
Type:
Medicine Detecting Instrument
Finished Dosage Form:
Granules
Precision:
High Precision
Certification:
CE, GMP, ISO
Voltage:
380V
Computerized:
Computerized

Product Description

Model YJX220 Drug Inspecting(Static Electricity Eliminating)Machine is a kind of new product developed and produced by our company through absorbing a advanced technology from abroad according to the requirement of the pharmaceutical industry at home. It can make the capsules and tablets (pill)drop on the stainless steel conveyer roller uniformly through the feeder. The drugs turn on the conveyer roller and meanwhile move forward with the conveyer roller, and then after static

electricity elimination and artificial inspection, substandard product will the picked out, thus achieving the aim of separating drugs and eliminating static electricity, Up to the GMP standard and without blind angle or spot on inspection ,this machine is a kind of ideal equipment for inspecting the appearances of capsules and tablets (pills).
1, The whole machine is made of stainless steel, it can reduce contact between operator and drug and is up to GMP standard
2, It is convenient for artificial inspection by step-less speed regulation of drug turning and conveying
3, With the function of static electricity elimination, it can prevent and reduce the static electricity of drug efficiently
4, With simple and easy operation, it can reduce labor intensity and raise working efficiency greatly.

Main Technical Parameters:

Weight	180kg
Power supply	220V 50HZ
Output:	0.75kw
Overall dimensions	1900X460X1230mm(LXWXH)
Medicine to be used:	Capsule00#-4#and pill, tablet diameter less than 25mm
