High Speed Fully-Automatic Manufacture Suppository Filling & Sealing Packing Machine



Inquire Add to Basket

Port:
Dalian, China
Production Capacity:
20 Sets/Year
Payment Terms:
L/C, T/T, Western Union, Paypal, Money Gram
Model NO.:
GZS-9A
Customized:
Customized
Condition:
New
Warranty:
1 Year
Product:
Suppository
Capacity:
16000-22000PCS/Hour
Dosage Per Suppository Cell:
0.5-3.7g
Shapes of Suppository:
Bullet Form, Torpedo Form
Packing Material:
PVC,PVC/PE
Center Distance:
17.4mm
Patterns on a Die :
9 Granules
Volume of Storing Fluid Vessel :
50L
Height of Feeding:
2000mm
Weight:
2500kg
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
meet with GMP standards
Origin:
Made in China
HS Code:
8422303090
Type:
Pharmaceutical Packaging Machinery
Finished Dosage Form:
Liquid
Precision:
High Precision
Certification:
CE
Voltage:
220V
Computerized:
Computerized

Product Description

High Speed Newest Fully-Automatic Suppository Filling & Sealing Packing Machine Manufacture

working video as following:

https://www.youtube.com/watch?v=7f5x86V-VS4&feature=youtu.be
https://www.youtube.com/watch?v=zesbLtyMzgw&feature=youtu.be

GZS-9A High Speed Suppository Filling and Sealing Production Line with output 16000-22000PCS/h which is made up of high speed suppository belt forming system, filling machine, cooling machine and sealing machine. PLC programmable control and human-computer interface operation the unit is simple to operate and with high automaticity.

High Speed Fully-Automatic Manufacture Suppository Filling & Sealing Packing Machine

All the processes can be made automatically including shell-making, infusing, cooling, shaping, and sealing of the suppositories. It is also of advantages of not infusing in the collapse and automatic rejection of it, automatic colour code deviation rectification, and detecting the infusion quantity. The unit is controlled by PLC procedure with human-machine interface operation and it is the highest automatic suppository equipment in the country today.

Technology Characteristics:

1. The adoption of PLC programmable control and human-computer interface operation the unit is simple to operate and with high automaticity.
2. With the function of automatic deviation rectification the characters' position can be controlled as you like. The suppositories have the neat and good appearance.
3. With the function of detecting collapse, infused quantity, the liquid level of the charging basket.
4. The infusion is adopted the servo motor system exactly adjusting the infusing quantity with menu-memory-function and simple to change the specifications.
5. The adoption of insert-type straight line infusion mechanism has the advantages of correct location, no drop medicine, and no adhesion phenomenon.
6. Cooling protection shut down, the band comes out continuously without end breaking and low waste rate.
7. Not infusing the wastes, auto-drill, and automatic rejection of them at the end of the Machine.
8. Interlock protection, intelligent alarm, and safety assurance.
9. Continuous band-making and sealing and the shearing numbers can be set at will.

Technical Parameter:

Output	16000-22000 capsules/h
Dosage per suppository cell	0.5-3.7g
Allowable Error of granular weight	± 5%
Shapes of suppository	Bullet form, torpedo form
Center distance	17.4mm
Patterns on a die	9 granules
Sheets specification	Height: 56-58mm, thickness: 0.15± 0.01mm
Volume of storing fluid vessel	50L
Height of feeding	2000mm
Power voltage	3-phase AC 380V
Total Power	17kw
Air pressure	0.55-0.65MP
Air consumption	1.0m3/min
Water consumption	480L/h
Overall dimensions	4800× 2040× 2200mm
Total weight	2500kg
