High Quality Laminated Plastic Tube Filling Sealing Machine Manufacture (BNF60)



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
30 Sets/Year
Payment Terms:
T/T, Western Union, Paypal, Money Gram
Model NO.:
BNF60)
Packaging Material Mechanical Properties:
Full Automatic Filling and Sealing Machine
Material Type:
Paste/Cream
Name:
Plastic Tube Filling Sealing Machine
Keywords:
Tube Filling Sealing Machine
High Speed Capacity:
60 PCS/Min
Tube Diameter(mm):
13~50
Pour Capacity (G):
1.5~300
Pour Precision(%):
> 0.5%
Tube Material:
Metal Tube, Plastic Tube, Laminated Tube
Available Ointment:
Water Ointment, Oil Ointment
Power(Kw):
13kw
Air Pressure:
0.6MPa
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
Meet GMP Standard
Origin:
Made in China
HS Code:
8422400000
Package size per unit product:
1950cm * 1000cm * 1800cm
Gross weight per unit product:
850kg
Packaging:
Plastic Soft Tube or Metal Tube
Automatic Grade:
Automatic
Packaging Material:
Plastic
Application:
Cosmetics, Cleaning, Detergent, Oil, Dairy Products, Skin Care Products, Hair Care Products
Usage:
Outpacking, Inner Packing
Type:
Filling and Sealing Machine

Product Description

High Quality Laminated Plastic Tube Filling Sealing Machine Manufacture (BNF60)

Why order our machine?

1.This machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement.
2.PLC controller and color touch screen are applied and made it possible for programmable control of the machine.
3.It can perform the filling for ointment, cream jellies or viscosity material, tail folding, batch number embossing (include manufacture date) automatically.
4.It's ideal equipment for plastic tube and laminated tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.
5. Guarantee for 1 year. supply free spare part within 1 year
6. Supply free technical service 24 hours on line
7. Supply FAT testing and SAT testing
8. Supply IQ,OQ document and Manual user's document

High Quality Laminated Plastic Tube Filling Sealing Machine Manufacture (BNF60)

Main Feature:

1. This Product have 9 stations, can choose different station and equip corresponding manipulator to meet different type of tail folding, sealing requirement for plastic tube, laminated tubes,
2. It is a multi-purpose machine.
Tube feeding, eye marking, tube interior cleaning (optional), material filling, sealing (tail folding), batch number printing, finished products discharging can be performed automatically (the whole procedure).

3. Tube storage can through motor to adjust up-down height as per different tube length. And can With external reversal feeding system, makes tube charging more convenient and tidy.
4. The mechanical linkage photo sensor precision tolerance is less than 0.2mm. reduce the chromatic aberration scope between tube and eye mark.
5. Light, electric, pneumatic integrative control, No tube, no filling. Lower pressure, auto display (alarm); The machine stop automatically if tube error or open the safety door.
6. Double-layer jacket instant heater with inside air heating, it won't damage the pattern outer wall of tube and achieves firm and beautiful sealing effect.

High Quality Laminated Plastic Tube Filling Sealing Machine Manufacture (BNF60)

Technical parameters:

BNF-60A
	Configuration Standard	Technical Parameters	Remarks
Infrastructure
	Main Machine Landing Area	(about) 2m2
	Working Area	(about)12m2
	Water Chiller Landing Area	(about)1m2
	Working Area	(about)2m2
	Whole Machine (L×W×H)	1950×1000×1800mm
	Integrated Structure	Union mode
	Weight	(about)850Kg
Machine case body
	Case Body Material	304
	Opening Mode of Safety Guard	Handle Door
	Safety Guard Material	Organic Glass
	Frame Below Platform	Stainless Steel
	Case Body Shape	Square-shape
Power, Main Motor etc.
	Power Supply	50Hz/380V 3P
	Main Motor	1.1KW
	Hot Air Generator	3KW
	Water Chiller	1.9KW
	Jacket barrel heating power	2 KW	Optional Additional cost
	Jacket barrel blending power	0.18 KW	Optional Additional cost
Production Capacity
	Operation Speed	30-50/min/max
	Filling Range	Plastic/laminated tube 5-250ml
	Suitable Tube Length	Plastic/laminated tube 50-210mm	Pipe length more than 210mm should customize
	Suitable Tube Diameter	Plastic/laminated tube 13-50mm
Pressing Device
	Pressing Guiding Main Component	CHINA
Pneumatic Control System
	Low Voltage Protection	CHINA
	Pneumatic Component	AIRTAC
	Working Pressure	0.5-0.7MPa
	Compressed Air Consumption	1.1m³/min
Electrical Control System
	Control Mode	PLC+Touch Screen
	PLC	TAIDA
	Frequency inverter	TAIDA
	Touch Screen	WE!
	Coder	OMRON
	Filling detect Photo electric cell	CHINA
	Total Power Switch etc.	ZHENGTA
	Color Code Sensor	JAPAN
	Hot Air Generator	LEISTER (Switzerland)
Suitable Packing Material & Other Devices
Suitable Packing Material		Aluminum-plastic composite tube and Plastic composite tube
Obliquely Hanging Lining-up Tube Storehouse		Speed Adjustable
Material contacting with filling material		316L Stainless Steel
Jacket layer hopper device		Temp. Setting according to material and filling demand		Additional cost
Jacket layer stirring device		In case of no material mixing, it remains fixed in hopper		Additional cost
Auto stamping device		Single side or double sides printing at the end of seal tube.		Double sides additional cost

Due to the continuous improvement of the equipment, if part of the electrical changes without notice.

Sample:

High Quality Laminated Plastic Tube Filling Sealing Machine Manufacture (BNF60)
