E-Liquids /Eye drop PET bottle Liquid Filling filling, plugging ∩ping Machine (with CE)
Our E-liquid filling sealing capping machine advantage: 1. function suitable production line Bottle in-feeding → filling→ ( plugging ) → cap placing→ capping →bottle out-feed 2.high filling precision:≤±1% 3.Filling range and production capacity:80pbm (according to 10ml PET bottle) 4. Qualified rate:≥99.9% 5. Save electricity : Power:220V 50HZ;total output:≤1.2kw 6. Use high quality SS316 stainless steel contact with liquid, other parts use SUS304 stainless steel
7. high quality PLC
Touch screen platform Host frequency variable speed controlling, automatically show the current frequency 8. this machine has CE certificate in order to export Europe factory. also meet with GMP and CGMP standards
9. Supply English IQ,OQ,document and English manual user's
10.Supply FAT testing and SAT testing
CBD E-liquid filling machine FAT testing working video as linkage:
https://youtu.be/PF_8swVvD7Q E-liquids/Eyedrop SAT testing working video for UK E-liquids factory as linkage
:https://youtu.be/yqfhaqtj71o
working priciple: CBD oil /E-Cig/E-liquids/Eyedrop filling plugging and capping machine suitable 5-30ml round PET bottle or similar bottle, The machine is composed by a load turntable, by piston pump (Metering pump) ceramic piston pump(alternative peristaltic pump) according to difference liquid viscosity; capacity by fill nozzles, plug ∩ sorter, Plug ∩ placer, cap screw-on system, unload tray. The bottle loading/unloading is done manually, through loading turntableØ500mm and unloading tray, or directly from an production line. It is designed and made accordance to GMP regulation.
Bottle unscrambler or bottle in-feeding machine supply the empty bottles into the conveyor of filling machine, the conveyor conveying the bottles to filling position of the index wheel, when the in-feed eye sensor detect bottles, the filling lifting mechanism will go down, the filling nozzles insert into the bottles, the pump liquid feeding and filling process is controlled by volumetric pump, when finish filling, the filling lifting mechanism will come up, the wheel push the bottle to (the plugging position, the vacuum sucking head sucks the plug, the cam transports the vacuum sucking head to upper of the bottle (the clamping device clamp the bottle), then press the plug in to the bottle, then transporting the plugged bottle to) the cap placing position, the cap inserting mechanism will insert the cap on the bottle, then the wheel transports the cap inserted bottle to the capping position, the capping head screws the cap, then the wheel transports the capping bottle to the conveyor to the next procedure. our machine detailed drawing (all parts name)
Filling sample:
Technical Features:
| Kind of bottle | Round eyedrop bottle or similar |
| Bottle size | Min. Ø20mm Max. Ø30mm |
| Speed | 80~100bpm on 10ml~5ml |
| Filling volume | 5ml~30ml |
| Filling accuracy | ±2% |
| Power | 220V 50/60Hz 1.5kw |
| Compress air require | 50~70L/min, 4~6bar |
| Machine size mm | Length 2500, width 1420, height 1500 |
| Machine weight: | 900kgs |
