Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine

  • Shanghai, China
  • 30 Sets/Year
  • T/T, Western Union, Paypal
  • DPP-80
  • Inner
  • General
  • 2400 Strips/H
  • 10-33 Times/Min
  • 105X70mm
  • 30-80mm
  • 70X80mm
  • 0.4-0.6MPa
  • Air Compressor≥0.3m3/Min
  • 380V/220V 50Hz 2.8kw
  • 0.75kw
  • 450kg
  • BSIT
  • Export Standard Wooden Case
  • Meet GMP Standard
  • Made in China
  • 8422303090
  • Food, Medical
  • Mechanical
  • Automatic
  • Feeding
  • Plastic
  • Blister
DPP-80 Blister Packaging machine

Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine


Features:

1.It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
2.Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user's requirement.
3.It adopts photoelectrical controlling system to make PVC, PTP, Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.

4.It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade.

5.The machine is suitable for industries of foodstuff, medicine, medical instruments, hardware, electronics and etc for packing.

Technical Specification:
Model DPP-80
Punch frequency 10-33times/min
Production capacity 2400plates/hour
Max. Forming area & Depth 105x70(standard depth <=15mm), Max. Depth 25mm( As adjusted
Standard Stroke range 30-80mm(can be designed as per user's required)
Standard plate size 80x70mm (can be designed as per user's required)
Air pressure 0.4-0.6Mpa
Compressed air required Air compressor≥0.3m3/min
Total power supply 380V/220V 50Hz 2.8Kw
Main motor 0.75Kw
PVC hard Film 0.15-0.5*110 (mm)
PTP Aluminum film 0.02-0.035*110 (mm)
Dialysis Paper 50-100g*110(mm)
Mould cooling Tap water or Recycling water
Overall Dimension 1840x590x1100 (mm)(LxWxH)
Weight Net 450kg Gross weight: 520kg
Noise index <75dBA

Work process:


1,Forming ( up and down heating)
2,Heating Sealing ( up heating)
3,Embossing
4,Impression
5,Cutter
6,Finished product output

Sample:

Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine

Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine
Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine
Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine
Dpp-80 Alu/PVC Tablet and Capsule Blister Packaging Machine
