NQF pharmaceutical machine Capsule Body and Cap Separating Opener Powder Recycle Machine
Choose our machine advantage
1.This is the world first machine designed to separate capsule and reuse powder, granules, pellets, or micro-tablets which is built to replace the traditional way of milling, sieving and retrieving powder.
2.machine is first of its kind to separate and retrieve round pellets and micro-tablets.
3.It is ergonomically designed; suitable for all capsule sizes with applicable change parts; easy to clean and maintain;
4.It is meet the GMP standard in the industry.
5. It is excellent machine to own by capsule manufacturing plants or R&D laboratories, where powders are extremely expensive and GMP is strictly required.
Drawing :
WORKING PRINCIPLE:
The capsules enter through the guide from the sorting system are pushed into separating device by the horizontal fork. The blades on the device hold the cap and body of the moving capsules. The capsule moving according to the opening rail formed by the blades; then, it will separate the body and cap of capsule completely.
TECHNICAL PARAMETER:
| Type Item | NQF300/600/800B | NQF1500B |
| Capacity | 100~800pcs/min | 1500pcs/min |
| Capsule Size | 0# 1# 2# 3# 4# | 0# 1# 2# 3# 4# |
| Power | ~220V 50HZ 1A | ~220V 50HZ 1A |
| Dimension | 600×600×1200mm | 600×600×1200mm |
| Weight | 45kg | 50kg |
| PACKING LIST | ||||
| NO. | Name | Type | Qty | Unit |
| 1 | Main Machine | NQF300/600/800/1500 | 1 | set |
| 2 | Molder with the machine | set | ||
| 3 | Optional molder | set | ||
| 4 | Spare Blade | set | ||
| 5 | Spare Blade | set | ||
| 6 | Spare Blade | set | ||
| 7 | Spare Blade | set | ||
| 8 | Special Tools | 2 | set | |
| 9 | Big Spring Plate | 1 | set | |
| 10 | Small Spring Plate | 6 | set | |
| 11 | QC cert | 1 | set | |
| 12 | Manule | 1 | set | |
Sample:
