Shanghai, China
50 Sets/Year
T/T, Western Union, Paypal, Money Gram
V
Verticle
Drum
Mixing
Cycle Operating
New
Stainless Steel Mixing/Mixer Machine Food/Granule
Mixing/Mixer Machine
Pharmaceutical, Food,Chemical,Medical
0.3
145L
90
20
0.75
1700
SUS304
BSIT
Export Standard Wooden Case
Meet GMP Standard
Made in China
842238000
V-Mixer
High Speed Mixer
Diving
Powder, Granules, Material
CE, ISO
Pharmaceutical
General of applications:
This machine is suitable for mixing two or more dry and powder or granule raw materials from pharmaceutical industry, chemical industry foodstuff industry and so on.
The structure of this machine is unique. Its mixing efficiency is high and no dead corner. It is made of stainless steel. Its inner and outer wall is processed through polishing. Its appearance is beauty. Its mixing is uniform. Its scope of application is wide. The forced stirrer can also be equipped in order to meet the requirements of raw materials that contain fine powder, cake and certain moisture as request.
Technical Parameter:
Item Specification | 0.05 | 0.15 | 0.3 | 0.5 | 1 | 1.5 | 2 | 3 | 4 | 5 |
Working volume(L) | 20 | 65 | 145 | 210 | 425 | 700 | 800 | 1250 | 1850 | 2300 |
Load(kg/batch) | 12 | 40 | 90 | 130 | 250 | 420 | 480 | 750 | 1100 | 1400 |
Speed main shaft(rpm) | 25 | 22 | 20 | 18 | 15 | 15 | 14 | 13 | 11 | 8 |
Power(kw) | 0.4 | 0.55 | 0.75 | 1.5 | 3 | 4 | 5.5 | 5.5 | 7.5 | 7.5 |
Height of rotating | 900 | 1300 | 1700 | 1840 | 2030 | 2300 | 2490 | 2850 | 3200 | 4600 |
Notes: all loading coefficient is 0.4-0.6.The productive capacity listed in the calculated in accordance with 0.5 of loading . coefficient and 0.8 of raw material density.
All datas are used for reference only . According to the condition of material our factory has right to change but not notice, pardon
Suitable industry:
.
General of applications:
This machine is suitable for mixing two or more dry and powder or granule raw materials from pharmaceutical industry, chemical industry foodstuff industry and so on.
The structure of this machine is unique. Its mixing efficiency is high and no dead corner. It is made of stainless steel. Its inner and outer wall is processed through polishing. Its appearance is beauty. Its mixing is uniform. Its scope of application is wide. The forced stirrer can also be equipped in order to meet the requirements of raw materials that contain fine powder, cake and certain moisture as request.
Technical Parameter:
Item Specification | 0.05 | 0.15 | 0.3 | 0.5 | 1 | 1.5 | 2 | 3 | 4 | 5 |
Working volume(L) | 20 | 65 | 145 | 210 | 425 | 700 | 800 | 1250 | 1850 | 2300 |
Load(kg/batch) | 12 | 40 | 90 | 130 | 250 | 420 | 480 | 750 | 1100 | 1400 |
Speed main shaft(rpm) | 25 | 22 | 20 | 18 | 15 | 15 | 14 | 13 | 11 | 8 |
Power(kw) | 0.4 | 0.55 | 0.75 | 1.5 | 3 | 4 | 5.5 | 5.5 | 7.5 | 7.5 |
Height of rotating | 900 | 1300 | 1700 | 1840 | 2030 | 2300 | 2490 | 2850 | 3200 | 4600 |
Notes: all loading coefficient is 0.4-0.6.The productive capacity listed in the calculated in accordance with 0.5 of loading . coefficient and 0.8 of raw material density.
All datas are used for reference only . According to the condition of material our factory has right to change but not notice, pardon
Suitable industry:
.
