It is used 10-30ml spray filling and capping line it is made of automatic bottle unscrambler, UV lighter sterilizer and spray filling and capping machine, DJ light inspector, adhesive Label Wrap-around machine and collection turntable and carton machine.
Spray filling and capping machine
Bottle in-feeding filling plugging cap placing capping bottle out-feed
1.Filling range: 5~20ml
2. Filling precision:≤±1%
3. Qualified rate:≥99.9%
4. Power:220V 50HZ;
5. Total output:≤1.2kw
6. Air pressure range:0.4-0.6Mpa;Air consumption10-25L/min
Adopt injection pump to fill high precision, large range of adjusting dosage.
The pump system don't absorb the medicament, good chemical stability, be able to resist high temperature and erosion.
Low level liquid receiver, convenient to clean.
Filling system has the function of shrinking, no drop leak.
Apply to fill various viscosity liquid.
Special manipulator and guiding device are equipped on it to ensure the spray cap reliably fitted on the opening of container.
Filling needle is diving bottom of bottle to fill and moving up slowly, avoid bubbling.
Filling and sealing are in one body of the machine, economical and low space possessing.
Magnetic moment capping system, adjust degree of tightness freely.
The whole machine is designed according to requirements of GMP. UV Light Sterilizer Power supply: 220V 50Hz, 150w UV Intensity: 140μW/cm2 Overall Dimension: 700x250mm Wrap-around Labeling machine 1. Labelling speed:from 80 to 200 pieces per minute(according to the different target object and the length of the labels)
2. Outer diameter of bottles:15 - 100mm;Bottle height: 20 - 150mm
3. Applicable range for the labels: Length range: 23 - 200 mm, Height range: 15 - 120 mm
4. Motor power:600W;Voltage:220V 50 to 60HZ
