Pharmaceutical Machine Hard Gelatin Capsule Polishing Machine (BSC100A)



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
20 Sets/Month
Payment Terms:
T/T, Western Union, Paypal, Money Gram
Model NO.:
BSC100A
Customized:
Non-Customized
Condition:
New
Warranty:
1 Year
Model:
Bsc100
Capacity:
150, 000 PCS/Hour
Capsule Model No.:
00# 0# 1# 2# 3# 4#
Power Supply:
1p 220/110V 50/60Hz 0.2kw
Feature:
Capsule Polishing and Sorting
Vacuum:
2.7m3 /Min; -0.01MPa
Compressed Air:
0.25m3 /Min; 0.3MPa
Materical:
SUS304
Size:
950X600X870 mm
Weight:
35kg
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
GMP
Origin:
Made in China
HS Code:
8422400000
Package size per unit product:
1150cm * 600cm * 1100cm
Gross weight per unit product:
40kg
Type:
Preparation Machinery
Finished Dosage Form:
Capsule
Precision:
Precision
Certification:
GMP, ISO
Voltage:
220V
Computerized:
Non-Computerized

Product Description

Pharmaceutical Machine Hard Gelatin Capsule Polishing Machine (BSC100A)

Choose our machine advantage:

BSC100 series capsule polishing and sorting machine is an advanced machine with new structure. To compare it with the traditional ones it has apparent advantage for its function and structure.

The main characters are:

1. Small size, good looking, adjustable height and angles. It can be connected to any types of capsule filling machines. Timely polishing while producing is realized to raise the polishing quality and efficiency.
2. It can automatically sort out capsules with low weight, empty body, scrap and loose piece to meet GMP standard.
3. High quality stainless steel is used inside the medicine- polishing chamber. Quick connecting parts are also adopted to dismount the equipment more easily and to clean more thoroughly.
4. Quick detachable brush and bearing are used for the ain axle. The brush and bearing can be dismounted easily. The hair of brush will not drop. Different sizes of brushes can be changed to meet the needs of different medicines.
5. A safety device is equipped. The speed of motor is controlled by converter. The polisher can continue to work for long time and stands moment of force.

polisher machine for working

Pharmaceutical Machine Hard Gelatin Capsule Polishing Machine (BSC100A)

Main key parts

Pharmaceutical Machine Hard Gelatin Capsule Polishing Machine (BSC100A)

Batch manufature for sale more customer

Pharmaceutical Machine Hard Gelatin Capsule Polishing Machine (BSC100A)

Technical Parameter:

Model	BSC100	BSC100A
Capsule Model No.	00# 0# 1# 2# 3# 4#
Max Output Capacity	150, 000 pcs/hour	300, 000 pcs/hour
Power Supply	1P 220/110V 50/60Hz 0.2kw
Dimension (mm)	950× 600× (H: 870 ~1000)	1150× 600× (H: 870 ~1000)
Weight (kg)	35kg	40kg
Vacuum	2.7m3 /min -0.01Mpa
Compressed Air	0.25m3 /min 0.3Mpa
