NJP500/800/1200 Pharmaceutical Equipment for High Quality Capsule Filler Machine
PLC Control and electrical components choose the international famous brand, such as MITSUBISHI, Siemens, SCHNEIDER, OMRON and so on, nicely, safely, reliability.
Screen control with computer windows scenically, advanced, efficient.
Advanced SEW motor and Siemens vacuum pump guarantee the stability of the machine.
The machine adopt the High-tech imported cam graduation system, which guarantee high performance, stable running, high graduation precision, compact structure, low noise.
Working video as following : https://youtu.be/Q7LvPeld3Vw Main Technical Data:
|Name ||NJP500 ||NJP800 ||NJP1200 |
|No. of die orifice ||4 ||6 ||9 |
|Max output (capsules/h) ||30000 ||48000 ||72000 |
|Vacuum ||27m3/h -0.02-0.08Mpa |
|Capsule number ||No. 00-5 |
|Filling percentage ||≥ 99% |
|Filling difference ||< ± 3 |
|Idle load noise db(A) ||< 70 |
|Power ||380V 50Hz 3KW |
|Size L x W x H (mm) ||800x750x1950 |
|Weight (kg) ||850 |
