BGB
BSIT
Shanghai, China
50 Sets/Month
L/C, T/T, Western Union, Paypal, Money Gram
Labortary Tablet Sugar Film-Coating Pharmaceutical Machine with coating pan interchangableApplication:
Main advantage:
1. BGB-1/3/5 coating pan interchangeable coating machine is a kind of excellent laboratory equipment which is used for film coating,
2. This equipment is manufactured according to the requirements of GMP standard.
3. With three interchangeable coating pans, make it more versatile and powerful for laboratory purpose.
4. It is SUS304/SS316 contact with product
5. meet with CE certificate
Main parts made of list:
| No. | Name | Specifications | Qty |
| 1 | BGB-5F Coating Machine | BGB-5F Coating Machine | 1 whole set |
| 1) 2) 3) 4) 5) 6) 7) | Main machine (Including heat exchanger, AHU) Peristaltic pump 1 piece spray gun+ rack Materials discharge device Coating drum rack & coating drums Magnetic stirrer Small slurry mixing device | 5F type OEM10132-313 Only for 5L Drums:5L,3L,1L | 1set 1set 1set 1set 1set 1set |
Main machine photo
3/5 L Photo of drum guide plate
1L Photo of drum guide plate
Features:
1. All in one design. hot-air inlet, coating and hot air exhaust are all in one machine.
2. Control and display the negative pressure of coating pan
3. Display the differential pressure of HEPA filter in supply air
4. Control and display the temperature
5. Control and adjust the atomization covered area.
6. Program control of spray gun and atomization
7. Design of gun clearing and anti-block
8. With the functions of memory and printing
9. With the function of interchangeable coating pan
10.With the functions of impulse and de-dusting.
Technical specifications :
| Model | BGB-5 |
| Coating Pan Diameter (mm) | 300,380,480 |
| Production Capacity (kg/batch) | 1, 3,5 |
| Rotating Speed Of Coating Pan(rpm) | 6-30 |
| Motor Power Of Main Machine (kw) | 0.37 |
| Temperature Range Of Hot Air | From normal environmental temperature to 80 centigarde |
| Filtration Accuracy Of Hot air (um) | 0.5 |
| Power Of Hot Air Motor (kw) | 0.25 |
| Power of Exhaust Motor (kw) | 0.37 |
| Power Of Electric Heating (kw) | 6 |
| Power Of Peristaltic Pump (kw) | 0.03 |
| Dimension Of Main Machine (mm) | 1250x900x1680 |
| Weight (kgs) | 400 |
Sample
