Hard Capsule Polisher Sorting Machine (BSC100A)



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
20 Sets/Month
Payment Terms:
L/C, T/T, Money Gram
Model NO.:
BSC100A
Customized:
Customized
Condition:
New
Warranty:
1 Year
Name:
Hard Capsule Polisher Sorting Machine
Keywords:
Capsule Polisher Sorting Machine
Feature:
Capsule Polishing and Sorting
Capsule Model No.:
00# 0# 1# 2# 3# 4#
Max Output Capacity:
150000-300000PCS/H
Power Supply:
1p 220/110V 50/60Hz 0.2kw
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
GMP
Origin:
Made in China
HS Code:
8422400000
Type:
Preparation Machinery
Finished Dosage Form:
Capsule
Precision:
Precision
Certification:
GMP
Voltage:
220V
Computerized:
Computerized

Product Description

Hard Capsule Polisher Sorting Machine (BSC100A)

Main application:
Capsule polisher is a kind of capsule polisher with function of sorter as well .It plays the function of not only the polishing for capsule . It can also automatically reject low weight capsule ;loose piece and fragments of capsules. It is suitable for all sizes of capsules without the need to change parts.

Main Feature:

With further implementation of GMP standard, capsule polisher has become necessary auxiliary equipment for the production of capsule preparation. At present market, the traditional capsule polisher has not been improved either in function or in structure. The main problems are:

1) The polisher cannot connect the main production machine to realize polishing while producing. If powder absorbing moisture easily, will affect polishing effects if in the air for concentrate polished long time. Polisher rely manual feeding result in low efficiency.

2) For those capsules low weight, empty, scrap and loose piece the polisher cannot sort out automatically. And manual sorting is not meet GMP standard.

3) The brush hair and bearing on the main axle cannot be dismounted. The manual bundled brush hair is easy to fall off while steel wire and bearing tend to rust. The soft net structure for sieve cylinder often sores up capsule during polishing to damage capsule surface.

4) These polishers general use DC motor, and carbon brush is easy to wear. It is not convenient to dismantle, not easy to clean the main axle and brush clearly, and it needs change main axle at first when production will be changed.

capsule sorting polisher is a new generation machine based on original polisher. Compare with the traditional one, it has apparent advantage on the function and structure.

Technical Parameters:

Max. Output	150000-300000 capsules/hour
Compressed air	250L/min 0.3Mpa
Vacuum	100m3/hour -0.014Mpa
Power Supply	220V 50HZ 1A 180W/110V 60HZ 2A 180W
Machine Size	950×600×1000 (mm)
Weight	40-45kg
