Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-500)

  • Shanghai, China
  • 30sets/Year
  • T/T, Western Union, Paypal, Money Gram
  • (BNJP-500)
  • Customized
  • New
  • 1 Year
  • Herbal Power Capsule Filling Machine
  • 30000PCS(1 Hour)
  • Hard Capsle 00#,0#,1#,2#,3#,4#,5#
  • 4 Double Lines
  • >= 99%
  • 7.5
  • 27m3/H -0.02~-0.08MPa
  • 1350*1020*1850mm
  • SUS304
  • 1400kg
  • BSIT
  • Export Standard Wooden Case
  • Meet GMP Standard
  • Made in China
  • 8422400000
  • Preparation Machinery
  • Capsule
  • High Precision
  • CE, GMP, ISO
  • 380V
  • Computerized
Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-600)

Application: This machine suitable for Pharmaceutical, medicine, and chemicals
suitable for powder or granule or liquid

NJP200 Hard Capsule Filling Machine/Encapsulation Machine


Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-500)
NJP1200 Hard Capsule Filling Machine/Encapsulation Machine

Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-500)
Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-500)

Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-500)

Sample:

Ce Pharmaceutical Machinery Hard Capsule Filling Machine/Encapsulation Machine (BNJP-500)
Machine Introduction:

BNJP Fully automatic capsule filling machine is the newest designed equipment ,which totally meet GMP, ISO, and USA FDA requirement. This machine is very nice, decent, and easy to operate, especially the electrical control cabinet is independent from machine, we can supply IQ OQ PQ document and CE certification .

This is a newly created full-automatic closed intermittent capsule filling machine with multiple tamping stations. It completes the following process: feeding capsule, detaching capsule, filling, ejecting defective capsule, closing capsule, discharging finished capsule automatically.

Machine features:

This machine can be equipped with vacuum loader for capsules and powder, which reduces the employer cost, all the operation is conducted on the touch screen, which is a highly automation machine of water, electricity and pneumatic.

1.Accurate orientation, Capsule vacuum positioned mechanism to make the capsule upload percentage over 99%.

2.Freely adjusting dosage, easy speed selection and closed capsule length adjustment.

3.PLC program control panel with LCD .touch screen operation, and monitoring function.

4.Displaying in-time speed and accumulative output.

5.Auto-trouble shooting, lack of material, lack of capsule, block in material channel and other mechanical trouble with be show on HMI ,Machine stop

6.Electrical Appliance control system approved to CE, and international standard.

7.Quick and accurate change part set-up, easy to remove rotary table and ring carrier assembly.

8.Fully enclosed dosing stations and rotating table for integration of the whole capsule filling plants.

9.working station cam runs under the good lubricating condition, extends the operating life of change parts. All the Precious are made by USA HASS and DMG CNC machine.

10. Alarm list

a. Alarm when doors and windows are opened

b. Main motor inverter alarm

c. Feeding motor overload alarm

d. Lock of capsules alarm

e. Lcok of powder alarm

f. Scram alarm

g. Off phase and phase sequence alarm protection

h. Vacuum overload alarm

i. Dust collector overload alarm

Main Technical Data:

Model

BNJP500

BNJP800

BNJP1200

BNJP1500

Output(1 hour)

30000

48000

72000

90000

No. of die orifice

4

6

9

12(double line)

Filling percentage

≥ 99%

≥ 99%

≥ 99%

≥ 99%

Power (kw)

380V.50Hz
3.5KW

380V.50Hz
3.5KW

380V.50Hz
3.5KW

380V.50Hz
7.5KW

Vacuum

27m3/h
-0.02~-0.08Mpa

27m3/h
-0.02~-0.08Mpa

52m3/h
-0.02~-0.08Mpa

27m3/h
-0.02~-0.08Mpa

Machine dimensions

1350*1020*1850

1350*1020*1850

1350*1020*1850

1220*960*2000

Weight (kg)

850Kg

850Kg

850Kg

1400Kg
