Automatic Box Carton Packing Machine for Sachet Bag



Inquire Add to Basket

Port:
Shanghai, China
Production Capacity:
30 Sets/Year
Payment Terms:
T/T, Western Union, Paypal, Money Gram
Model NO.:
SMZ-125K
Speed:
30-100PCS/Min
Weight:
1400kg
Packing Product:
Sachet or Packing Bag, Bottle, Ampoule, Pill
Name:
Carton Box Packing Machine
Material:
SUS304 Stainless Steel
Vacuum Suction:
0.6MPa
Air Consumption:
5-8L/Min
The Quality of Specification:
55-70G/M2
Specification Size:
(60-200)X(80-160)mm
Total Supply:
1.5kw
Trademark:
BSIT
Transport Package:
Export Standard Wooden Case
Specification:
Meet GMP Standard
Origin:
Made in China
HS Code:
8422400000
Certification:
ISO9001, GMP, ISO, CE
Application:
Commodity, Machinery & Hardware, Textile, Alcohol, Apparel, Dining, Medical, Food
Driven Type:
Electric
After-Sales Service Provided:
Engineers Available to Service Machinery Overseas
Type:
Carton Packaging Machinery
Automatic Grade:
Automatic

Product Description

SMZ-125K Grain Cartoning packing Machine
Automatic Box Carton Packing Machine for Sachet Bag

cartoning machine, box packing machine, grain packing machine, automatic packing machine.

Main uses:

Automatic Box Carton Packing Machine for Sachet Bag

The device by the Division I after box machinery equipment for more than four years new research and development of a dedicated to the grain bag, of all types of particulate bag of drugs, cosmetics, automatic counting,automatic box.

Main technical data:

Item	Parameters
Run speed	30-80cartons/min
Vacuum suction	0.6Mpa
Air consumption	5-8 liter/min
The quality of specification	55-70g/m2
The quality of carton	250-350g/m2
Specification	(60-200)x(80-160)mm
Dimension of carton	(LxWxH)(50-110)x(50-120)x(25-70)
Power supply	380V50Hz
Total supply	1-1.5kw
Dimension of equipment	3500x1150x1600
Machine weight	1200kg
