JMS-300 Peanut Butter Stainless Steel Colloid Mill Machine
Scope of Application:
Food-processing industry:juice, jam, beans, peanuts, cream, beverage, malted milk, egg yolk, ice-cream, etc.
Chemical industry concerned with products for daily use:grease, water quality, powder cream high-level cosmetics; shoe polish, tooth paste, soap, cleaning detergent, bath extract.
Chemical industry: lubricating grease, paints, coloring agents, emulsified asphalt, cementing compound, etc.
Other industries:plastic industry, pharmaceutical industry, textile industry, construction industry and coinage industry.
Main Feature:
Colloid mill product is a machine for fine processing the fluid materials. It combines a variety of performance such as homogenizer, ball grinder, and three roller machine, shearing machine, stirrer etc. It also has superior ultra-fine grinding, dispersing and emulsifying, homogenizing, mixing and other effects.
The material through processing, grain size will reach 2~50 micrometer, homogeneity more than 90%, and it's the ideal equipment for ultra- fine processing.
Sample:
Main technical parameters:
| Name | Standing colloid mill | Variable colloid mill | Lateral colloid mill | |||||||
| Type | JM-80 (J) | JM-130 (J) | JMS-50 | JMS-80 | JMS-130 | JMS-180 | JMS-240 | JMS-300 | JMS-450 | JMW-120 |
| Material processing size(µ m)(single cycle or multi-cycle) | 2-50 | 2-50 | 2-50 | 2-50 | 2-50 | 2-50 | 2-50 | 2-50 | 2-50 | 2-80 |
| Capacity (t/h)(change with the nature of material | 0.07-0.5 | 0.5-2 | 0.005-0.03 | 0.007-0.5 | 0.5-2 | 0.8-6 | 4-15 | 6-20 | 10-40 | 1-4 |
| Power of main electrical motor(kw) | 4 | 11 | 1.1 | 4 | 11 | 15 | 37 | 55-75 | 160/200 | 11 |
| rpm of electrical motor (r/min. ) | 2890 | 2930 | 1750-5000 | 1600-5000 | 1750-5000 | 1600-5000 | 1600-2950 | 1750-2970 | 1750-2970 | 2930 |
| Overall size (L x W x H) mm | 45 X46 X133 | 55 X55 aX140 | 53 X26 X58 | 68 X38 X93 | 99 X44X 105 | 135 X55 X134 | 135 X60 X128 | 135 X60 X142 | 198 X73 X187 | 107 X34 X74 |
| Gross weight (kg) | 190 | 320 | 70 | 210 | 420 | 550 | 1300 | 1600 | 3000 | 150 |
