RD-1
BSIT
Shanghai, China
50 Sets/Week
L/C, T/T, Western Union, Paypal, Money Gram
Pharmaceutical Tablet Melting Point Tester Machine RD-1
Poduction Description
Melting point is the temperature of something turning to liquid from solid. Testing it is the main method to detect some characters such as purity etc.
RD series are suitable for testing Melting points of drug, spice and dye etc.
Applicable standard
National standard( Chinese codex ) /2015
Corporate standard(Thickness tester) Q/12XQ0185-2010
Features:
Testing the temperature with high-precision sensor. emending nonlinear error automatically.
Using auto frequency-conversion control technology, with high accuracy in controlling temperature and little linear error in heating speed.
Auto-memorizing and noting preset data and melt point, holding without power.
Auto magnetism stirrer, with the bath oil even in temperature.
Auto-preset temperature, auto-heat, display preset and real-time data alternately in time.
Automation: auto-test, auto-diagnose, auto-alarm
Technical Parameter :
| Range of melting point | (50~270)ºC |
| Accuracy | <200ºC ≯±0.5ºC ≥200ºC ≯±1.0ºC |
| Usage temperature | (15~35)ºC |
| Range of preset temperature | (50~260)ºC |
| Oil bath | methyl silicone oil |
| Oil bath cup | 250ML high beaker |
| Rate | (0.5,1.0,1.5,3.0)ºC/min |
| Accuracy of Rate | ≤10% |
| Power of the heater | 200W |
| Power | 220V/50Hz/500W |
| Dimension | (320x180x310)mm3 |
Carton Package
Wooden Case for more than 3 sets of testers
Pharmaceutical Tablet Melting Point Tester Machine RD-1
Poduction Description
Melting point is the temperature of something turning to liquid from solid. Testing it is the main method to detect some characters such as purity etc.
RD series are suitable for testing Melting points of drug, spice and dye etc.
Applicable standard
National standard( Chinese codex ) /2015
Corporate standard(Thickness tester) Q/12XQ0185-2010
Features:
Testing the temperature with high-precision sensor. emending nonlinear error automatically.
Using auto frequency-conversion control technology, with high accuracy in controlling temperature and little linear error in heating speed.
Auto-memorizing and noting preset data and melt point, holding without power.
Auto magnetism stirrer, with the bath oil even in temperature.
Auto-preset temperature, auto-heat, display preset and real-time data alternately in time.
Automation: auto-test, auto-diagnose, auto-alarm
Technical Parameter :
| Range of melting point | (50~270)ºC |
| Accuracy | <200ºC ≯±0.5ºC ≥200ºC ≯±1.0ºC |
| Usage temperature | (15~35)ºC |
| Range of preset temperature | (50~260)ºC |
| Oil bath | methyl silicone oil |
| Oil bath cup | 250ML high beaker |
| Rate | (0.5,1.0,1.5,3.0)ºC/min |
| Accuracy of Rate | ≤10% |
| Power of the heater | 200W |
| Power | 220V/50Hz/500W |
| Dimension | (320x180x310)mm3 |
Carton Package
Wooden Case for more than 3 sets of testers
