FM450 Automatic box Shrink Film Packing Machine
1. This machine can packing single or group, it is a automatic hot shrink film packing machine that design for assembly line and mass packing
2. Users can choose automatic feeder to realize no works operation feeding base the detailed specification of products, kinds of conveyor to ensure material no moving or threshing.
3. No damage packing product and increase the efficiency by anti -cut safety clutch device
4. Line type sealed after packing, clear and beautiful.
5. Adjust belt length, speed, temperature lonely, easy and accuracy. Electrical feature:
1. PLC: Use imported PLC, inverter control, realize continuously variable transmission control, adjusting during running dynamically.
2. New vertical sealing heating, sealed in low temperature, reduce hear film
3. There are two temperature zone in hot shrink stove, control temperature automatic
4: High efficiency hot air cycle, ensure shrink quality Finished product: Technical data:
|1 ||Packing capacity: ||30-180bag/min |
|2 ||Packing specification: ||Length 70-400mm, width: 32-200mm, height: 5-120mm |
|3 ||Total dimensions: ||Length x width: 7200mmx 965mm |
|4 ||Power: ||3.7kw, one phase 220V |
|5 ||Total weight: ||1000kg |
|6 ||Packing material: ||Paper/PE, OPP/PE, OPP/AL/PE etc, packing materials that are suitable for heating |
