Availability: | |
---|---|
BSF
BSIT
Shanghai, China
50 Sets/Month
L/C, T/T, Western Union, Paypal, Money Gram
1 set
wooden case packing
Grinding machine/pulverizer/crusher machine/mining machine/milling machine/crushing machine/mining equipment.
Features:
1) Contact material as SS304
2) Output 50-300 kg per hour
3)the face plate is glass and thickness is 10mm
4)two lock and top and below at door
5) Silicon sealing
6) Collect material with container
7) Output 50-300 kg.
8) Sieve, 120 mesh 2 pcs.
9) Gearing behind the machine should be full closed.
10)Discharge sleeve ( to connect bin for product with discharge hole)
11)Energy stop button
Technical parameters:
Mode | Main shaft speed | Crushing fineness | Crush capacity | Infeed max size | Motor | Size |
SF130 | 7000r/min | 10~120 mesh | 2-5kg/h | 5×5×5 | 1.1kw | 520×360×820 |
SF180 | 4000r/min | 10~120 mesh | 10~20kg/h | 8×8×8 | 2.2kw | 420×600×1000 |
SF250 | 4000r/min | 10~120 mesh | 50~250kg/h | 10×10×10 | 5.5kw | 860×500×1360 |
SF320 | 4000r/min | 10~120 mesh | 80~300kg/h | 10×10×10 | 7.5kw | 880×520×1450 |
SF40 | 3400r/min | 10~120 mesh | 160~800kg/h | 10×10×10 | 7.5kw | 900×550×1450 |
Grinding machine/pulverizer/crusher machine/mining machine/milling machine/crushing machine/mining equipment.
Features:
1) Contact material as SS304
2) Output 50-300 kg per hour
3)the face plate is glass and thickness is 10mm
4)two lock and top and below at door
5) Silicon sealing
6) Collect material with container
7) Output 50-300 kg.
8) Sieve, 120 mesh 2 pcs.
9) Gearing behind the machine should be full closed.
10)Discharge sleeve ( to connect bin for product with discharge hole)
11)Energy stop button
Technical parameters:
Mode | Main shaft speed | Crushing fineness | Crush capacity | Infeed max size | Motor | Size |
SF130 | 7000r/min | 10~120 mesh | 2-5kg/h | 5×5×5 | 1.1kw | 520×360×820 |
SF180 | 4000r/min | 10~120 mesh | 10~20kg/h | 8×8×8 | 2.2kw | 420×600×1000 |
SF250 | 4000r/min | 10~120 mesh | 50~250kg/h | 10×10×10 | 5.5kw | 860×500×1360 |
SF320 | 4000r/min | 10~120 mesh | 80~300kg/h | 10×10×10 | 7.5kw | 880×520×1450 |
SF40 | 3400r/min | 10~120 mesh | 160~800kg/h | 10×10×10 | 7.5kw | 900×550×1450 |
